MinebeaMitsumi Develops Electric Vacuum Pump Powered by Its Brushless DC Motor
MinebeaMitsumi Inc. (Head office: Nagano Prefecture; Representative Director, Chairman CEO: Yoshihisa Kainuma; hereinafter "MinebeaMitsumi") hereby announces that it has newly developed an electric vacuum pump utilizing its in-house manufactured brushless DC motor.
The primary feature of this newly developed electric vacuum pump is its compact size paired with highly efficient suction capability. Despite its lightweight and compact design—weighing approximately 70 g and measuring φ32 mm × 55 mm (excluding projections), which is smaller than a single D-size battery—it achieves a flow rate of 3.0 L/min and a vacuum pressure of -60 kPa, demonstrating high efficiency superior to competitors(*1). Furthermore, the three-cylinder diaphragm minimizes pulsation, offering exceptional quietness. With these features. It is optimal for robots and medical equipment that require low noise so that operating sound does not cause stress when working near people, as well as for semiconductor production equipment that demands powerful suction within a limited footprint.
By adopting MinebeaMitsumi's BKL series
brushless DC motors, which have a long track record of production within the company, this product meets market demands by offering longer life, higher efficiency, and greater miniaturization compared to conventional electric vacuum pumps. Samples are available upon request. Going forward, MinebeaMitsumi will continue development while considering modifications to winding specifications and other features to satisfy customer requirements.
Competitor comparison (*1)
(*1) Based on our research as of May 2026, referencing publicly available information from each company.
Main Applications
- Collaborative Robots and Robot Hands
- Automated Guided Vehicles
- Vacuum Lifters / Vacuum Lifting Systems
- Factory Production Lines
- Picking
- Semiconductor Production Equipment
- Medical Analytical Instruments
- Production Facilities
Product Photo
Product Specifications
| Application | Suction (Negative pressure) |
|---|---|
| Power Supply Voltage [V] | 24V DC |
| Current Consumption [A] | 0.2A or less |
| Suction Pressure [kPa] | -60 |
| Flow Rate [L/min] | 3.0 |
| Operating Temperature Range | 5 to 40℃ |
| Noise Level [dB(A)] | 60 or less |
| Dimensions | φ32x65mm |
| Weight [g] | Approx. 70 |
| Drive Method | PWM (5V) |
| Motor | Brushless DC |
Production Plan
| Mass Production Start | : October 2027 (Scheduled) |
|---|---|
| Production Volume | : 10,000 pcs/month (Target) |
| Production Location | : China |
About MinebeaMitsumi's Brushless DC Motors
MinebeaMitsumi's brushless DC motors are highly reliable motors featuring our own ball bearings in their internal structure. We offer a broad lineup ranging from several watts to several kilowatts for applications from consumer electronics to automotive, with custom modifications available to meet specific customer requirements. A wide variety of options is available, including basic inner-rotor and outer-rotor types, as well as frameless models and wheel-integrated units.
About MinebeaMitsumi
MinebeaMitsumi is an INTEGRATED(*2) precision components manufacturer. The company specializes in ultra-precision technologies, ranging from core products such as miniature and small-diameter ball bearings—which ensure smooth machine rotation—to protection ICs for single-cell lithium-ion batteries. The company's diverse portfolio includes motors, sensors, and semiconductors. While often unseen, MinebeaMitsumi's ultra-precision technologies support daily life across a wide array of fields, including home appliances (air conditioners, vacuum cleaners, and hair dryers), gaming consoles, IT devices like smartphones and PCs, as well as automotive, aerospace, and medical equipment.
(*2) "INTEGRATION" means 'combining' rather than 'simply adding together', creating new value through synergy by bringing together all the resources of the group.
